18.5 inch RK3288 Android all in one touch screen pc
Specification:
| Total parameter | Diagonal Size | 18.5'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 5:4 | |
| Enclosure Color | Black | |
| Speakers | Two 5W internal speakers | |
| Mechanical | Unit Size (WxHxD mm) | 454x277x50 |
| VESA Holes (mm) | 75x75,100x100 | |
|
Computer |
Mother board |
RK3288 ARM Cortex-A17 |
|
Memory |
2G+8GB |
|
| USB | 5 x USB | |
| LAN | 10/100/1000 Ethernet ,support PXE boot & remote wake up | |
| Wi-Fi | Wi-Fi 802.11 a/b/g/n/ac | |
| BIOS | AMI | |
|
LCD Specification |
Active Area(mm) |
409.8×230.4 mm (H×V) |
|
Resolution |
1366(RGB)×768 (WXGA) |
|
|
Dot Pitch(mm) |
0.100×0.300 mm (H×V) |
|
|
Viewing angle(Typ.)(CR≥10) |
85/85/80/80 (Typ.)(CR≥10) |
|
|
Contrast (Typ.) (TM) |
1000:1 |
|
|
Brightness (typical) |
LCD Panel: 250 nits PCAP: 220 nits |
|
|
Response Time (Typ.)(Tr/Td) |
3/7ms |
|
|
Support Color |
16.7M , 72% (CIE1931) |
|
|
Backlight MTBF(hr) |
30000 |
|
|
Touchscreen Specification |
Type |
Cjtouch Projected Capacitive(PCAP) touch screen |
|
Multi touch |
10 points touch |
|
| Power |
Power Consumption (W) |
DC 12V /5A ,DC head 5.0x2.5MM |
|
Input Voltage |
100-240 VAC, 50-60 Hz |
|
|
MTBF |
50000 hr at 25°C |
|
|
Environment |
Operating Temp. |
0～50°C |
|
Storage Temp. |
-20～60°C |
|
|
Operating RH: |
20%～80% |
|
|
Storage RH: |
10%～90% |
|
| Accessories | Included | 1 x Power Adapter,1 x Power Cable, 2 x brackets |
| Optional | Wall Mount, Floor Stand/Trolley, Ceiling Mount, Table Stand | |
| Warranty | Warranty Period | 1 Year Free Warranty |
| Technical Support | Lifetime |
Components:
Power Cord with Switching Adapter *1 Pcs
Bracket*2 Pcs
Applications:
♦ Information Kiosks
♦ Gaming Machine, Lottery , POS, ATM and Museum Library
♦ Government projects and 4S Shop
♦ Electronic catalogs
♦ Computer-based traning
♦ Eductioin and Hospital Healthcare
♦ Digital Signage Advertisement
♦ Industrial Control System
♦ AV Equip & Rental business
♦ Simulation Application
♦ 3D Visualisation /360 Deg Walkthrough
♦ Interactive touch table
♦ Large Corporates
FAQ
1. How about your products Quality?
We have a strict quality control system. All products ordered from our factory are inspected by a professional quality control team.
2. What After-sales service can you offer ?
We provide after-sales service team, all problems and questions will be resolved by our after-sales service team.
3. Are you a factory or trading company?
We are a factory located in Dongguan city,China.
4. l haven't done business with your company before, how can i trust yourcompany?
Our company has been in this market for 12 years,which is longer than mostof our fellow supplier, we've got a lot certificate, such as, CE,RoHS,FCC andISO9001.
-
