23.8 inch LED-Light PCAP touch screen pc monitors

Short Description:

With eye-catching front ,back or edge of addressable LED illumination surrounding the display, CJTOUCH LED-Framed touchmonitor is available in various sizes, designed for external mounting outside your cabinet which keeps exciting players immerse with captivating play. It is an ideal touch solutions for the rigors of gaming environments such as the casino, gaming, and amusement industry.

Send email to us

Product Detail

Product Tags

Specification:

Display Specifications
Characteristic	Value		Comment
LED	With back around LED
LCD Size/Type	23.8"a-Si IEILCD
spect Ratio	16:9
Active Area	Horizontal	527.04 mm
	Vertical	296.46mm
Pixel	Horizontal	0.2745
	Vertical	0.2745
Panel Resolution	1920(RGB1080(FHD][6OHz)		Native
Display Color	16.7Million		6-bits+Hi-ERC
Contrast Ratio	1000:1		Typical
Brightness	250 nits		Typical
Response lime	10ms		Typical
Viewing Angle	Horizontal	178	Typical
	vertiral	178
Video Signal Input	vGAand DVIand HDMI
Physical Spedfications
Dimensions	Width	584 mm
	Height	353 mm
	Depth	55.5mm
weight	Net Weight7kgs	Shipping Weight9.5kgs
Box Dimensions	Length	660 mm
	Width	440 mm
	Height	180 mm
Electrical Specifications
Power Supply	DC 12V4A		Power Adapter Included
	100-240 VAC,50-6OHz		Plug Input
Power Consumption	Operating	38w	Typical
	Sleep	3w
	off	1w
Touch Screen Spedfications
Toudh Technologv		Project Capacitive Touch Screen 10Touch Point
Touch lnterface		uSB(Type B)
os Supported	Plugand Play	WindowsAll(HID),Linux(HID)(Android Option)
Driver		Driver Offered
Environmental Specifications
Condition		Specification
temperature	operating	0°C+50℃
	Storage	-20℃~+60℃
Humidity	perating	20%~80%
	Storage	10%~90%
MTBF		30000 Hrs at 25℃
