19 inch touch screen monitor High brightness PCAP Touch

Short Description:

· Highly quality industrial monitors

· Optional touchscreens like IR, SAW, PCAP

· Easy-to-install with open frame rear-mount display

· Multiple mounting options (75/100mm VESA mount and side brackets)

· High brightness from 1000nits to 1500nits optional

· Long lasting product cycle for continuity thru all phases of project

Send email to us

Product Detail

Product Tags

Specification:

General
Model	COT190-CFF03-1000
Series	Water-proof and Flat Screen
LCD Type	19” Active matrix TFT-LCD
Video Input	VGA, DVI and HDMI
OSD controls	Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply	Type: External brick Input (line) voltage: 100-240 VAC, 50-60 Hz Output voltage/current: 12 volts at 4 amps max
Mount Interface	1)VESA 75mm and 100mm 2)Mount bracket, horizontal or vertical
LCD Specification
Active Area(mm)	376.320(H)×301.060(V)
Resolution	1280×1024@60Hz
Dot Pitch(mm)	0.294×0.294
Nominal Input Voltage VDD	+5.0V(Typ)
Viewing angle (v/h)	80°/85°
Contrast	1000:1
Luminance(cd/m2)	1000
Response Time(Rising)	3.6s/1.4s
Support Color	16.7M colors
Backlight MTBF(hr)	30000
Touchscreen Specification
Type	Cjtouch Projected Capacitive touch screen
Multi touch	10points touch
Touch Life Cycle	10 millions
Touch System Interface	USB interface
Power consumption	+5V@80mA
External AC Power Adapter
Output	DC 12V /4A
Input	100-240 VAC, 50-60 Hz
MTBF	50000 hr at 25°C
Environment
Operating Temp.	0～50°C
Storage Temp.	-20～60°C
Operating RH:	20%～80%
Storage RH:	10%～90%

Components:

COT190-CFF03-1200 -ASM-D02-2019112910447_00

USB Cable 180cm*1 Pcs,

VGA Cable 180cm*1 Pcs,

Power Cord with Switching Adapter *1 Pcs,

Bracket*2 Pcs.

https://www.cjtouch.com/19-inch-ip65-waterproof-infrared-pc-monitor-touch-screen-product/

Applications:

♦ Information Kiosks
♦ Gaming Machine, Lottery , POS, ATM and Museum Library
♦ Government projects and 4S Shop
♦ Electronic catalogs
♦ Computer-based traning
♦ Eductioin and Hospital Healthcare
♦ Digital Signage Advertisement

♦ Industrial Control System
♦ AV Equip & Rental business
♦ Simulation Application
♦ 3D Visualisation /360 Deg Walkthrough
♦ Interactive touch table
♦ Large Corporates

FAQ

1. Why should I choose CJTOUCH?
We are a professional manufacturer of touch screen Touch PC and touch monitor with 12 years experience.

2. What's your main products?
Our main products are SAW/PCAP/IR touch screen,SAW/PCAP/IR touch screen monitors ,desktop monitor and All in one touch PC

3. What sizes do you offer ?
SAW touch screen/monitor range from 8”-32”
IR touch screen/monitor range from 10.4”-110”
PCAP touch screen/monitor range from 5”-65”
Resistive touch screen/monitor range from 10.4”-21.5”
Touch foil range/monitor from 15”-86”
