27 touch screen monitor High brightness industrial LCD monitor Featured Image
  • 27 touch screen monitor High brightness industrial LCD monitor
  • 27 touch screen monitor High brightness industrial LCD monitor
  • 27 touch screen monitor High brightness industrial LCD monitor
  • 27 touch screen monitor High brightness industrial LCD monitor

27 touch screen monitor High brightness industrial LCD monitor

Short Description:

• 1000 nits, sunlight readable

• Anti glare/ Anti-reflection option

• With light sensor for auto dimming option

• Front IP65 waterproof and dustproof

• Covered with 3mm tempered glass for vandal-proof

• Can work well with drop water on the screen

• Wide temperature range

• Support wall mounting, embedded mounting, desk stand mounting etc


Product Detail

Product Tags

Specification:

Display Specifications
Characteristic Value Comment
LCD Size/Type 27” a-Si TFT-LCD
Aspect Ratio 16:9
Active Area Horizontal 597.6mm
  Vertical 336.15mm
Pixel Horizontal 0.31125
  Vertical 0.31125
Panel Resolution 1920(RGB)×1080 (FHD)(60Hz) Native
Display Color 16.7 Million 6-bits + Hi-FRC
Contrast Ratio 3000:1 Typical
Brightness 1000 cd/m² (Typ.) Typical
Response Time 7/5 (Typ.)(Tr/Td) Typical
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Typical
Video Signal Input VGA and DVI and HDMI
Physical Specifications
Dimensions Width 659.3mm
  Height 426.9mm
  Depth 64.3 mm
Electrical Specifications
Power Supply DC 12V 4A Power Adapter Included
  100-240 VAC, 50-60 Hz Plug Input
Power Consumption Operating 38 W Typical
  Sleep 3 W
  Off 1 W
Touch Screen Specifications
Touch Technology Project Capacitive Touch Screen 10 Touch Point
Touch Interface USB (Type B)
OS Supported Plug and Play Windows All (HID) ,Linux (HID) (Android Option)
Driver Driver Offered
Environmental Specifications
Condition Specification
Temperature Operating -10°C ~+ 50°C
  Storage -20°C ~ +70°C
Humidity Operating 20% ~ 80%
  Storage 10% ~ 90%
MTBF 30000 Hrs at 25°C
5
6
9

Components:

COT270-CFK03-1000-ASM-D04-202072414274

USB Cable 180cm*1 Pcs,

VGA Cable 180cm*1 Pcs,

Power Cord with Switching Adapter *1 Pcs,

Bracket*2 Pcs.

https://www.cjtouch.com/19-inch-ip65-waterproof-infrared-pc-monitor-touch-screen-product/

Applications:

https://www.cjtouch.com/

♦ Information Kiosks
♦ Gaming Machine, Lottery , POS, ATM and Museum Library
♦ Government projects and 4S Shop
♦ Electronic catalogs
♦ Computer-based traning
♦ Eductioin and Hospital Healthcare
♦ Digital Signage Advertisement

♦ Industrial Control System
♦ AV Equip & Rental business
♦ Simulation Application
♦ 3D Visualisation /360 Deg Walkthrough
♦ Interactive touch table
♦ Large Corporates

https://www.cjtouch.com/
https://www.cjtouch.com/
https://www.cjtouch.com/

FAQ

1. What kind of frame material and glass material do you choose?
We have our own supporting sheet metal building materials factory, as well as our own glass production company. We also have our own dust-free clean workshop for the production of laminated touch screens, and our own dust-free clean workshop for the production and assembly of touch displays.
Therefore, a touch screen and a touch monitor, from research and development, design to production, are all independently completed by our company, and we have a very mature set of systems.

2. Do you provide customized product service?
Yes, we can provide, we can design and produce according to the size, thickness and structure you want.

3. How much thickness do you usually use for touch screens?
Usually 1-6mm. Other thickness sizes, we can customize according to your needs.
